INFO
| Category |
Mobile and all terrain cranes |
| Brand / Model |
XCMG XTC55L6 |
| Year |
2021 |
| Hours |
2,845 h |
| Country |
China |
| General Grade |
|
| Mascus ID |
E98AF13A |
PRICING
| Select Currency |
USD |
| Price Excluding Tax |
50,560 $ |
DETAILS
| Date of Latest Inspection |
2026-02-10 |
| Amount of Previous Owners |
1 |
| Gross Weight |
97,003 lbs |
| Maximum Lift Capacity |
121 lbs |
| Max Lifting Capacity at End of Jib |
121 lbs |
| Min Boom Length |
49.2 feet |
| Emission Level |
Stage V / Tier V |
| Boom Length |
45.9 feet |
| Min Luffing Jib |
45.9 feet |
| Luffing Jib |
45.9 feet |
| Jib Length of Crane |
45.9 feet |
| Maximum Lift Height |
209 feet |
| Hook Height of Crane – Horizontal Jib |
49.2 feet |
| Hook Height of Crane – Luffed Jib |
49.2 feet |
| Crane Type |
Hydraulic jib |
| Original Color |
original |
| Engine Manufacturer |
original |
| Transport Dimensions (LxWxH) |
537.4 x 100 x 148.43 inches |
| Carrier Type |
Wheeled |
| Condition Info/Guarantee |
1 year |
| Front Tires / Undercarriage Remaining |
98% |
| Rear Tires Remaining |
2 |
| Delivery Terms |
FCA, FOB, CIF, EXW |
| Certificates |
EPA, CE |
| Attachments |
We have all the parts for the machinery: ROCK BUCKET/SKELETON BUCKET / LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL |
| Business Hours |
24 hours, holidays and Sundays |
| Address |
Shanghai City, China |
| Contact |
Nina |
| Whatsapp |
+86 18055199047 |
| Mobile |
+86 18055199047 |
| Wechat |
18055199047 |
| Email |
|
Packaging Details
- Flat frame is more suitable for large construction equipment without disassembly.
- Containers are the cheapest and fastest.
- Bulk carriers are more suitable for large construction equipment.
- Ro-ro shipment is fast and suitable for all kinds of machines.
You can choose any mode of transportation according to your needs.
Accessories
Additional Information
Basic Parameters:
- Overall Dimensions: Overall length 13,650mm, overall width 2,540mm, overall height 3,770mm.
- Total Mass in Travel State: 44,000kg.
- Axle Load: 9,000 + 9,000 + 13,000×2 kg.
- Minimum Rated Radius: 3m.
- Swing Radius of Turret Rear: 3,830mm.
Driving Parameters:
- Maximum Travel Speed: 90km/h.
- Minimum Stable Travel Speed: 2.5-3km/h.
- Minimum Turning Diameter: 24m.
- Maximum Gradient Climbing Capacity: 45%.
- Minimum Ground Clearance: 303.5mm.
- Approach Angle: 16° (10° including front protection).
- Departure Angle: 13°.
- Braking Distance: ≤10m.
- Fuel Consumption per 100km: 35L.
Power Parameters:
- Engine Model: MC11.36-40, SC10E340Q4.
- Rated Engine Power: 268/1,900 kW/(r/min), 251/1,900 kW/(r/min).
- Rated Engine Torque: 1,800/1,000-1,400 N·m/(r/min), 1,550/1,300 N·m/(r/min).
Lifting Performance Parameters:
- Maximum Rated Total Lifting Capacity: 55 tons.
- Maximum Lifting Moment of Basic Boom: 2,058 kN·m.
- Maximum Lifting Height: 10.7m for basic boom, up to 49.1m for the longest main boom, and up to 63.8m for the longest main boom + jib.
- Maximum Lifting Speed: 130m/min.
- Standard Counterweight: 6.5 tons, optional 3-ton movable counterweight.
Working Speed Parameters:
- Boom Telescoping Time: 350s for full extension.
- Boom Luffing Time: 50s for full lifting.
- Slewing Speed: 2r/min.
